PA hotmelt low pressure molding
Side Injection
Side Injection Air Over Oil Cylinder Machine

BETA 1100H

Side Injection Air Over Oil Cylinder Machine

l  Air over oil hydraulic cylinder gives more clamping force for larger part.

l  Compact design with 5 liter melting tank integrated with machine.

l  User-friendly interface, 7" Touch screen with multi-language.

l  Two thermal control zones for precise melt control.

l  Equipped with light curtain and dual palm buttons for operator safety.

l  Upgraded new gun makes the injection more reliable.



Application



  Our machines are engineered for low pressure molding applications. Using specialty resins to encapsulate delicate parts.

  Applications including : automotive electronics, PCBA,coil, fiber-optic, LED lighting, wire, cable, etc.




Specification

Machine Size / Weight

975 mm x 1150 mm x 1880 mm / 400 kg

38.39 in x 45.28 in x 74.02 / 882 lbs

Footprint

975 mm x 1150 mm  |  38.39 in x 45.28 in

Working Station Height

840 mm  |  33.07 in

Packing Size / Weight

1010 mm x 1200 mm x 1950 mm / 440 kg

39.76 in x 47.24 in x 76.77 in / 970 lbs

Melting Tank Model &Q'ty[1]

MT-05-1100H x 1

Auto Feeding System

Optional

Maximum shot size

5.8 g / RPM

Injection rate

5 grams / second

Gun Model & Tip

LPMS-G02x1 / 36.4°or90°

Heated Hose Model &Q'ty

N / A

Electricity[2]

200-240VAC / 1 Phase / 50 Hz

Temperature Control Zones

2

Temperature Range

Ambient up to 250°C / 485°F

Max .Power

4.5Kw

Pump Motor

120W

Min. Air Pressure

0.5MPa  |  73 Psi

Air Consumption

0.1m3 / min  |  3.5ft3 / min

Clamping

Air Over Oil Cylinder

Clamping Force

Max.5 Tons (Option 10Tons)

Clamping Stroke

Max .4.92 in (Option 5.91 in)

Ejector

Pneumatic

Ejector Force

980 N

Ejector Stroke

10 mm

Control System

7 ”HMI , PLC controlled

Safety Protection

Dual palm buttons , Light curtain

Mold Set Size

230 mm x 120 mm x 150 mm / 25 kg

9.06 in x 4.72 in x 5.91 in / 55.16 lbs

Max . Mold Set Size

300 mm x 200 mm x 150 mm

11.81 in x 7.87 in x 5.90 in

Max . Part Size

100 mm x 90 mm x 18 mm

3.94 in x 3.54 in x 0.71 in




Dimension
