TS-200WJ high speed galvanometer laser welding machine is a combination of galvanometer scanning and welding system. Fast welding speed, especially suitable for laser precision spot welding of small thin-wall parts. The production efficiency is 3-4 times higher than that of conventional laser spot welding. The galvanometer and laser are directly controlled by software, and special laser welding software based on Windows platform is provided. Welding points or graphics can be directly input and edited in special software, or edited by AutoCAD,CorelDRAW and other software, or imported into DWG or PLT files. The machine is stable, easy to operate and the maintenance is simple.
Weldable material: spot welding,butt welding and stitch welding for metal workpiece (various kinds of carbon steel, stainless steel, aluminum alloy, gold or silver or other precious metal raw materials).
Applied in high efficiency spot welding or sealing welding in electronic, communication, hardware and other industries. Includes battery, cell phone shield metal, mobile phone metal shell, capacitor metal case, computer hard disk, micro-motor, sensor, metal shield network, razor blades and other types of electronic products.
Specification
Model | TS 200WJ |
Power | 200W |
Laser wavelength | 1064nm |
Output laser pulse width | 0.2-20ms |
Continuous laser welding frequency | 1-25HZ |
Output laser current | 100-300A |
Depth of welding | 0.1-1.0MM(depends on material) |
Minimal beam diameter | 0.2MM |
Repeat scanning accuracy | ±0.005MM |
Welding point speed | ≤20 points/second |
Cooling system power | 1.5P |
Machine power | <6KW |
Electricity | 220V 50Hz |
Machine dimension | 650*1850*1200 |
